- Thiết bị điện tùy chọn cho việc vận hành và theo dõi hệ thống chân không
- Vòng đệm được thiết kế chính xác ngăn ngừa nhiễm bẩn và bẫy ngưng tụ công suất cao.
- Tốc độ bơm định danh: 1430/1700 m3/h (840/1000 cfm).
- Rotor tự cân bằng động năng và bánh răng tiếp đất chuẩn xác giảm tiếng ồn và độ rung
- Kích thước 750 x 1289 x 1195 mm và tổng khối lượng 570 / 590 kg.
- Các tùy chọn bơm điều khiển bằng biến tần cho phép tốc độ bơm không đổi trên toàn thế giới, bất kể tần số dòng điện.
[/porto_ultimate_heading][vc_separator color="custom" style="solid" accent_color="#dddddd"][/vc_column_inner][/vc_row_inner][vc_row_inner css=".vc_custom_1589991781482{margin-bottom: 30px !important;}" el_id="How-It-Works"][vc_column_inner][porto_ultimate_heading main_heading="NGUYÊN LÝ VẬN HÀNH" main_heading_font_weight="" sub_heading_font_weight="" alignment="left" main_heading_margin_bottom="5"][/porto_ultimate_heading][vc_separator color="custom" style="solid" accent_color="#dddddd"][/vc_column_inner][/vc_row_inner][vc_row_inner css=".vc_custom_1589991754794{margin-bottom: 30px !important;}" el_id="Technology"][vc_column_inner][porto_ultimate_heading main_heading="CÔNG NGHỆ" main_heading_font_weight="" sub_heading_font_weight="" alignment="left" main_heading_margin_bottom="5"][/porto_ultimate_heading][vc_separator color="custom" style="solid" accent_color="#dddddd"][/vc_column_inner][/vc_row_inner][vc_row_inner css=".vc_custom_1589991816578{margin-bottom: 30px !important;}" el_id="Specifications"][vc_column_inner][porto_ultimate_heading main_heading="THÔNG SỐ KỸ THUẬT" main_heading_font_weight="" sub_heading_font_weight="" alignment="left" main_heading_margin_bottom="5"]
Tốc độ bơm định đanh, 50/60 Hz |
1430/1700 m3/h (840/1000 cfm) |
Tổng áp lực cuối (khí chấn lưu đóng) |
≤ 7 x 10-3 mbar (≤ 5 x 10-3 Torr) |
Tổng áp lực cuối (khí chấn lưu mở) |
≤ 2 x 10-2 mbar (≤ 1.5 x 10-2 Torr) |
Áp lực khởi động của bơm roots |
≤ 30 mbar (≤ 22.5 Torr) |
Nguồn điện (50/60 Hz) |
5,5 + 5,5 / 6,3 + 7,5 kW (7.3 + 7.3 / 8.4 + 10.0 HP) |
Điện áp nguồn (50 Hz) |
230 / 400 V |
ĐIện áp nguồn (60 Hz) |
208-230 / 460 V |
Mức độ tiếng ồn (được đo dụa theo EN ISO 2151 (50/60 Hz)) |
74 / 76 dB(A) |
Lượng dầu dùng |
1,5 + 7,0 lít (1.6 + 7.4 qt) |
Nhiệt độ xung quanh khi vận hành |
+12 +40 °C (+54 +105 F) |
Nhiệt độ bảo quản |
-15 +70 °C (+5 +158 F) |
Kích thước D x W x H |
750 x 1289 x 1195 mm (29.5 x 50.7 x 47 in) |
Khối lượng (50/60 Hz) |
570 / 590 kg (1260/1300 lb) |
