- Analytical-scale purification LC system ideal for purification of multi-milligram quantities of materials
- Highly reliable and robust LC system improves your ability to manage ever-increasing workload demand
- Dynamic flow range up to 5 mL/min at maximum 1300 bar allows versatile application within a wide range of analytical-scale purification workflows
- Future-proof investment through upgrade with additional modules such as refractive index, fluorescence, or evaporative light scattering detectors, or single quadrupole LC/MSD
- Low-dispersion fraction collection for precise isolation of compounds of interest from your analytical run
- Collection of up to 4 x 96 fractions in microtiter plates, or up to 216 fractions in glass tubes with 4 outer diameters of tubes available
- Integrated and automated fraction delay sensor technology for increased purity and recovery of collected fractions
- Upgradeable fraction capacity based on your demand: improved lab efficiency through orthogonal analytical information only available from isolated compounds
- Fully upgradable to enhance the system’s capabilities and functionality based on your demand
- Clean software infrastructure through Agilent OpenLab CDS ChemStation for familiar and reliable operation
[/porto_ultimate_heading][vc_separator color="custom" style="solid" accent_color="#dddddd"][/vc_column_inner][/vc_row_inner][vc_row_inner css=".vc_custom_1589991781482{margin-bottom: 30px !important;}" el_id="How-It-Works"][vc_column_inner][porto_ultimate_heading main_heading="How it works" main_heading_font_weight="" sub_heading_font_weight="" alignment="left" main_heading_margin_bottom="5"][/porto_ultimate_heading][vc_separator color="custom" style="solid" accent_color="#dddddd"][/vc_column_inner][/vc_row_inner][vc_row_inner css=".vc_custom_1589991754794{margin-bottom: 30px !important;}" el_id="Technology"][vc_column_inner][porto_ultimate_heading main_heading="Technology" main_heading_font_weight="" sub_heading_font_weight="" alignment="left" main_heading_margin_bottom="5"][/porto_ultimate_heading][vc_separator color="custom" style="solid" accent_color="#dddddd"][/vc_column_inner][/vc_row_inner][vc_row_inner css=".vc_custom_1589991816578{margin-bottom: 30px !important;}" el_id="Specifications"][vc_column_inner][porto_ultimate_heading main_heading="Specifications" main_heading_font_weight="" sub_heading_font_weight="" alignment="left" main_heading_margin_bottom="5"]
Biocompatible |
No |
Bioinert |
No |
Column Capacity |
4 |
Column ID Reader Option |
Optional |
Depth |
468 mm |
Flow Range |
up to 5 mL/min with G7120A and G7104A |
Injection Range |
0.1-100 µL
0.1 to 1500 µL with Multi Draw Kit
|
Intelligent System Emulation Technology |
No |
Line Voltage |
100-240 VAC |
Maximum Number of Fractions |
384 |
Maximum Number of Solvents |
4 up to 15 with additional Solvent Selection Valve |
Maximum Number of Temperature Zones |
2 with G7116B
1 with Vial Sampler with Integrated Column Compartment |
Pump Type |
Binary |
Special Features |
Delay Sensor
Automated Delay Volume Calibration |
System Pressure Operating Range |
up to 1300 bar |
Width |
980 mm |
