Multimode Inlet

Multimode Inlet

The Multimode Inlet (MMI) increases analytical capability, allowing the ability to inject large volumes of sample and split away the solvent, dramatically increasing the sensitivity. Inject cool-temperature thermally labile compounds and then ramp temperatures quickly to transfer to the column.

The injection technique that is used for a method can be tailored to the compounds. Using the MMI the GC can meet current analytical needs and provides flexibility to meet future regulatory requirements.


  • Large volume injection capabilities
  • Injection modes include hot and cold split and splitless, pulsed split and splitless, solvent vent, and direct inject mode
  • Agilent Turn Top inlet for easier maintenance
  • Temperature range of -160 ºC to 450 ºC
  • Agilent Solvent Elimination Calculator assists user in setting parameters for large-volume injection
  • Cooling options include air, liquid nitrogen and liquid carbon dioxide
  • Compatible with Merlin Micro-Seal septum


How It Works



Analysis of Extractables from a Pressurized Metered Dose Inhaler (pMDI) Using GC/MSD

Extractables were identified in pressurized metered dose inhaler components using two Agilent 5977A Series GC/MSD Systems.

Achieving Higher Sensitivities Using GC-FID with the Agilent Multimode Inlet (MMI)

Application note for maximizing the sensitivity of hydrgocarbons injected with the Agilent Multimode Inlet (MMI) with GC-FID.

Lowering Detection Limits for Routine Analysis of Pesticides Residues in Foods Using the Agilent 7000C Triple Quadrupole GC/MS

An analytical method that is well established for the 7000 Series Triple Quadrupole GC/MS has been employed to demonstrate performance of the 7000C Triple Quadrupole GC/MS.

Automated Preparation of Simulated Distillation Standards and Samples for ASTM Methods D2887, D7213, D7398 and D6352 using the 7693A System with Easy SamplePrep Software

Application note for automated preparation of simulated distillation standards and samples

Environmental Semivolatiles Using an Agilent Multimode Inlet for Maximum Sensitivity

Application note for Environmental Semivolatiles Using an Agilent Multimode Inlet for Maximum Sensitivity

Achieving Lower Detection Limits Easily with the Agilent Multimode Inlet (MMI)

Application note for achieving lower detection limits easily with the Agilent Multimode Inlet (MMI)

EN 14105 Using a Multi-Mode Inlet and Agilent J&W Select Biodiesel for Glycerides

B100 biodiesel was assayed for free and total glycerol content to EN 14105 with an Agilent Multi-Mode Inlet and UltiMetal Agilent J&W Select Biodiesel for Glycerides.

Agilent Multimode Inlet for Gas Chromatography

Designed to give you ease of use and maximum flexibility, the Agilent Multimode Inlet does everything the standard split/splitless (S/SL) inlet can do and a great deal more.
